1 Netia Network Infrastructure

2 Backbone Fiber Optics Infrastructure Backbone FO length 5000km 7 and 8 duct pipe standard in the backbone Minimum 6 duct pipe free resources in all most important connections 48j FO standard 2j leased FO cable: -, Płock-Kalisz and - FO infrastructure to all major cities International Point Of Interconnect in Cieszyn route to Prague and Frankfurt Stargard Sczeciński Koszalin Piła Słupsk Bydgoszcz Brzeg Kalisz Sieradz Konin Kępno Gdynia Tczew Starogard i Grudziądz Włocławek Płock Łódź Modlin Kielce Radom Starachowice Puławy Ostrowiec Świętokrzyski Tarnowskie Góry Own FO LL FO Rybnik Cieszyn Tychy Bielsko-Biała 2

in Cieszyn route to Prague and Frankfurt Stargard Sczeciński Koszalin Piła Słupsk Bydgoszcz Brzeg Kalisz Sieradz Konin Kępno Gdynia Tczew Starogard i

3 Metropolitan Fiber Optics Infrastructure FO Metropolitan Area Networks Metro FO length 4452km Typical capacity 72j Own duct pipe 3233km Metropolitan FO infrastructure in 44 biggest cities of Poland including Warsaw Silesia area /Gdynia Bydgoszcz/ 3

pipe 3233km Metropolitan FO infrastructure in 44 biggest

4 DWDM Systems Słupsk Over 40 DWDM sites in all major cities All DWDM systems guarantee 32 and more channels 10Gb each First commercial implementation of 40 Gb IP over DWDM link in long-distance New Silesia Ring supports 40 Gb lambdas by default All new links, which are planned to build, are prepared to support 40x40Gb capacity Central management systems allow to real time provision and maintenance works CWDM system are used to support metro and client links International IC with Czech Telecom and Interroute Koszalin Piła Brzeg Bydgoszcz Kalisz Kępno Starogard i Sieradz Włocławek Płock Łódź Modlin Puławy Radom Starachowice Kielce Rybnik WDM Add-Drop CWDM DWDM Cieszyn Bielsko-Biała 4

management systems allow to real time provision and maintenance works CWDM system are used to support metro and client links International IC with Czech Telecom and

5 SDH Systems Koszalin Słupsk Gdynia Over 1500 sites in all major cities One homogenous management system with end to end provisioning capabilities Software and Hardware releases in the network is kept up to date. All newest functionalities are implemented and already used. Alcatel based SDH network Core network based on biggest GMPLS/SDH switches on the market. Majority services are fully protected (All in backbone) Gorzów Wielkopolski Zielona Góra n x STM-16 n x STM-64 Piła Brzeg Bydgoszcz Kalisz Sieradz Kępno Starogard i Grudziądz Cieszyn Włocławek Płock Łódź Częstochowa Olsztyn Modlin Kielce Radom Puławy Ostrowiec Świętokrzyski Tarnobrzeg Rzeszów Białystok 5

Alcatel based SDH network Core network based on biggest GMPLS/SDH switches on the market.

6 Carrier Ethernet and IP Systems Telia Tiscali TATA Communications Two independent networks carrying all packet traffic: Carrier Ethernet and Metro Ethernet for L2 services; IP network for other services Ethernet Network 30 Ethernet nodes with 10Gb uplink, 150 Ethernet nodes with 1Gb uplink Koszalin Słupsk 2x10GE 10GE STM-16 Łódź T-Systems TP Polpak over 550 ADSL nodes with 1Gb uplink Piła Bydgoszcz IP Core Network 15 Core IP nodes with 10Gb uplink and first 40 Gb IPoDWDM link in Poland 4 POI with International IP Transit Providers Kępno Kielce 10GE GE Rzeszów 6

1Gb uplink Koszalin Słupsk 2x10GE 10GE STM-16 Łódź T-Systems TP Polpak over 550 ADSL nodes with 1Gb uplink Piła Bydgoszcz IP Core Network 15

7 Collocations Netia operates 5 Collocation Centers Tier III class, dedicated for clients telecommunication equipment and data centers: - fully redundant high-capacity AC or DC power feeds, - battery UPS and 48VDC back-up, - automated diesel genset, - controlled temperature and humidity via fully redundant HVAC system, - fire threat protection and suppression, - 24/7 monitoring and access control, - customized collocation spaces: locking cabinets, cages or suites, - high standard SLA covering collocation and IP connectivity, - support via 24/7 7

and humidity via fully redundant HVAC system, - fire threat protection and suppression, - 24/7 monitoring and access control, -

8 Netia Point of Presence Netia POPs: Hosts [19] RSU [618] FITL [139] Collocation [51] Wimax BS [38] Wimax Terminals [103] Radio [230] Interconnects [230] LLU [187] 8 8

9 Thank you for your attention
